Oil Downhole Tools 2.125 Inch Pear Drop Rope Socket Wireline And Slickline

Brand Name : Ruixin

Model Number : 1.25inch 1.75inch 1.875inch 2.125inch 2.5inch

Certification : API

Place of Origin : China Baoji

MOQ : 1

Payment Terms : T/T

Supply Ability : 1 set 2 weeks

Delivery Time : 1-2 weeks

Packaging Details : Wooden Box

Name : Wireline Pear Drop Rope Socket Wireline Tool String

Material : Alloy Steel&Nickel Alloy

Size : 1.25inch 1.75inch 1.875inch 2.125inch 2.5inch

FN : 1.187inch~2.313nch

Connection : SR,QLS,BLQJ,HDQRJ

Application : Slickline& Wireline

Advantage : Simple& low maintenance design

Contact Now

Oil Downhole Tools 2.125 Inch Pear Drop Rope Socket Wireline And Slickline

Wireline Pear Drop Rope Socket Wireline Tool String

Ⅰ.Introduction (B)

The rope socket is used to securely attach wireline to the toolstring. Available in various sizes,has pear drop,spring type,slip type

II. General Technical Parameters (A)

Size Fishing neck Connection
1.25＂ 1.187＂ 15/16UN
1.5＂ 1.375＂ 15/16UN
1.5＂ 1.375＂ 15/16UN
1.75＂ 1.375＂ 15/16UN
1.875＂ 1.75＂ 1-1/16UN
2.125＂ 1.75＂ 1-1/16UN
2.5＂ 2.313＂ 1-9/16UN

Note. More customized parts are available upon request.

III. Structure characteristics (C)

The pear drop rope socket consists of a body with an external fishing neck, sleeve and a brass wedge.

It is a female thread on the bottom to connect the tool string. The tapered fishing neck on the top is used to fish and cut off the wireline efficiently. The sleeve and wedge are accommodated in the body with smooth inner hole.

Ⅳ.Maintenance:

1. Regularly inspect that whether the lockpin and lock sleeve are damaged or deformed and change them in time;

2. After using the steel wire for a period of time, cut off a length of the head and make a new rope socket head to avoid that the steel wire end is over fatigued to cause the steel wire to be broken.

Oil Downhole Tools 2.125 Inch Pear Drop Rope Socket Wireline And Slickline

Tools Can Be Manufactured To Any Size Required. Welcome to contact us at any time.
